Please allow approximately 6 weeks for processing.
Yamaha GT-750 Direct Drive Record Player
Manufacturer: Yamaha
Model: GT-750
Years of manufacture: 1984 - 1986
Made in: Japan
Power consumption: 5 W
Dimensions: 532 x 212 x 406 mm (W x H x D)
Weight: 15.4 kg
Drive: Direct, quartz-controlled
Speed: 33 1/3 and 45 rpm
Wow & flutter: ±0.006%
Rumble-to-noise ratio: 82 dB
Turntable: 36 cm die-cast aluminum
The turntable is made of 30 mm thick die-cast aluminum, has a diameter of 360 mm, and a weight of 3 kg. Combined with a 400 g SBR mat, it achieves an inertia of 600 kg/cm².
The motor is a four-phase, 8-pole, coreless DC motor with a starting torque of 1.2 kg/cm² and a quartz PLL system for stable rotation.
The tonearm is a statically balanced, S-shaped tonearm with gimbal suspension, achieving an initial sensitivity of 7 mg horizontally and vertically. It also features a die-cast zinc arm base and an extra-thick machined brass column with a diameter of 27 mm.
It is also equipped with an anti-skating mechanism with a threaded suspension and a height adjustment.
It features a die-cast aluminum headshell with a thicker connection area to prevent harmful vibrations.
The cabinet is made of 88 mm (including base plate) of 18 mm thick, high-density particle board and is rigidly mounted.
The feet are equipped with springs and rubber composite insulators.
