Restored turntable Yamaha PF-800 semi-automatic in desired color

  • Operating voltage can be selected for each country
  • Housing in desired color
  • Semi-automatic with lift function and limit switch
  • Belt drive
  • High-quality components made of stainless steel
  • MM pickup: Ortofon OM5E
  • Basic dimensions: 47.3cm x 37.6cm x 18cm
  • RCA audio cable (permanently installed)
  • Height-adjustable tonearm and turntable feet
  • Removable headshell
  • Subchassis mounted in a swinging manner
Housing in desired color
dust cover and hinges
control panel
record weight 300g
Device feet (height adjustable)
LED lighting
1.690,00 €
incl. 0% VAT , incl. shipping costs (10Kg)
  • Delivery time: 2 - 3 Workdays (Other countries)


Yamaha PF-800 in desired color

Semi-automatic with lift function and limit switch

  • Operating voltage can be selected for each country
  • Housing in desired color

Our record players are lovingly put together and assembled by hand. Each of them is unique and differs in model, color or veneer grain. The high-quality housings are restored or newly manufactured using qualified craftsmanship. Electrical components are checked, moving parts are oiled and wearing parts are replaced. A final endurance test completes the complex work.

Technical data:

Drive: belt drive
Speed: 33 1/3 and 45 (manual fine adjustment possible)
Synchronization fluctuations: 0.028%
Rumble noise distance: 80dB
Turntable: main plate die-cast aluminum, sub-platter die-cast zinc
Pitch: 6%
Outputs: 2x RCA cable, 1x ground cable
Power consumption: 7 watts
Dimensions: 47.3 x 37.6 x 15.4cm
Weight: approx. 15 kg

Special features:

Removable headshell
Subchassis, mounted to swing freely on three conical springs
high-quality materials
Twin tonearms
Tonearm height adjustable
Lift Adjust (lifting point of the tonearm can be adjusted at the end of the record)

The following work will be carried out:

Revision of electronic and mechanical components
Components required for conversion or installation
Setting and balancing the different speeds
Adjustment and adjustment of the suspension
Checking and adjusting the tonearm and cartridge
Thorough cleaning of the entire record player
Execution of an endurance test

MM pickup:
The Ortofon OM5E is a full-fledged pickup. It impresses with its temperament and neutral basic character. The OM5E features an elliptical stylus that allows for balanced and distortion-free playback.

The original housing is refurbished, the wooden structure is removed, painted with several layers of paint and then sealed with clear varnish. Four height-adjustable spikes made of chrome-plated stainless steel are installed on the bottom of the housing. The spring caps are re-turned from full stainless steel and the old suspension is replaced with stronger suspension. Power cable and cinch cable are replaced.

Device feet:
Spikes made of chrome-plated stainless steel. To ensure that the record player is decoupled from low-frequency vibrations, the chassis is equipped with height-adjustable spikes. Resonances and feedback are thus effectively prevented.
